GPU SuperServer SYS-420GP-TNR 4U Dual Processor (3rd Gen Intel® Xeon®), Dual-Root GPU System with Up to 10 PCIe GPUs | High Performance Computing, Rendering, VDI, AI/Deep Learning Training
מפרט
סוג מארז
4U
ספק כח
4000W Redundant Titanium Level power supplies
Hard Drive 2.5
24x2.5" hot-swap NVMe/SATA/SAS drive bays (8x2.5" NVMe dedicated)
Expansion slots
12 PCIe 4.0 x16 FHFL slots
מידות
W=437 H=178 D=737 mm
Rackmount
כן
הערות
Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors | Supports up to 270W TDP CPUs (Air Cooled)
מידע
Key Applications
- High Performance Computing, Rendering, VDI, AI/Deep Learning Training
Key Features
- Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors;
- Intel® C621A Chipset;
- 32 DIMM Slots; Up to 8TB DRAM; Up to 8TB Intel® Optane™ Persistent
- Memory (up to 12TB with DRAM); 3200/2933/2666 ECC DDR4
- LRDIMM;RDIMM; Intel® Optane™ Persistent Memory 200 series;
- AIOM/OCP 3.0 Support; 12 PCIe Gen 4.0 X16 FHFL Slots;
- Flexible networking options;
- Total 24x 2.5" Hot-swap drive bays; 2x M.2 NVMe for boot drive only; 8x HOT
- SWAP 2.5” NVMe; 8x HOT SWAP 2.5” SATA/SAS (AOC required); 8x HOT SWAP
- 2.5” SATA;
- 8 Hot-Swap Heavy Duty Fans with Optimal Fan Speed Control;
- 4x 2000W redundant Titanium level power supplies.
Hardware
- Trusted Platform Module (TPM) 2.0
- Silicon Root of Trust (RoT) – NIST 800-193 Compliant
- Features
- Cryptographically Signed Firmware
- Secure Boot
- Secure Firmware Updates
- Automatic Firmware Recovery
- System Lockdown
